HKS Hipermax S Coilovers (ZD8)

Specifications:

Front:

Damping Force Adjustment: 30 stages

Base Valve: -

Full Length Adjustment: Available

Upper Mount: Pillow Ball

Configuration: Inverted

Damper/Spring: Monotube

Spring Rate Change at Shipping: Available

Damping Force Adjustment via Wire: -

Helper Spring (Spring Rate N/mm): - / Available (19.8)

Rear:

Damping Force Adjustment: 30 stages

Base Valve: -

Full Length Adjustment: Available

Upper Mount: Rubber

Configuration: Upright

Damper/Spring: Monotube

Spring Rate Change at Shipping: Available

Damping Force Adjustment via Wire: -

Helper Spring (Spring Rate N/mm): - / Available (19.8)

Ride Height Information (in mm):

FRONT:

Shipping Height: 644

Test Height: ← (Test results to be reflected)

Maximum Upper Limit to Maximum Lower Limit: 670 ～ 614

Driveable Upper Limit to Driveable Lower Limit: 670 ～ 614

Normal Car Height Comparison: -26 (Compares to normal car height, lowered by 26mm)

REAR:

Shipping Height: 647

Test Height: ← (Test results to be reflected)

Maximum Upper Limit to Maximum Lower Limit: 675 ～ 614

Driveable Upper Limit to Driveable Lower Limit: 675 ～ 614

Normal Car Height Comparison: -28 (Compares to normal car height, lowered by 28mm)
